Element Range

Element 40 Permanent Magnet

  • Powerful 1200w motor with a two-speed mechanical gearbox.

  • 13kg in total weight.

  • Suitable for drilling up to 40mm diameter by 50mm depth.

  • CutSmart Technology – designed to protect your motor and cutter, prolonging tool life.

  • Quick release interchangeable handle – allowing you to operate the mag drill from either side and improving accessibility.

  • Internal cabling reduces the risk of damage and downtime for your magdrill.

  • Internal cooling – keeping your mag drill cool and allowing you to drill for longer.

  • Small in size (514mm), this magnetic drill performs in difficult environments.

  • Innovative permanent magnet technology: maintains its hold even during power loss.

  • Dual motor protection, minimising wear and downtime of this magdrill.
CutSmart
Thumbnail of
Thumbnail of
Thumbnail of
Thumbnail of http://CutSmart
Thumbnail of
FIND A DISTRIBUTOR Get In Touch

SPECIFICATION

Model Number

Element 40/1 Permanent Magnet / Element 40/3 Permanent Magnet
Motor Specification

110V 1200W / 230V 1200W
No load RPM

Low Gear: 300 RPM/High Gear: 600 RPM
Max Cutting Capacity

ø40 x 50mm deep
Drill Chuck Capacity

ø13mm
Overall Dimension

Height: 514mm / Width: 185mm with Capstan / Length: 285mm with Guard
Machine Weight

13kg
Magnetic Adhesion

5,000N
Magnet Size

180mm x 90mm
Safety Features

Cutsmart™ Technology / Fixed Guard / Magnetic Detection / Mechanical Clutch
DOWNLOAD MANUAL Rotabroach Catalogue

Element 40 Permanent Magnet
